S5 System • System description

Circuit board keys and LEDs

B 44
B 46
Fig. 28: Circuit board keys and LED
Item Name
B 43 Circuit board keys and LEDs for RP 150 and MRP 85/1
(for registration of the shaft encoder with cable har-
ness; not shown here)
B 44 LED light guide, 7-element (in this case for RP 150)
B 45
Circuit board keys and LEDs for DRP 85 und MRP 85/2
(for registration of the shaft encoder with cable har-
ness; not shown here)
B 46 LED light guide, 7-element (in this case for DRP 85)
B 47 Contact pin to circuit board computer board HKR B 4
3.44
B 43
B 45
B 46
Number
HKD 0327
HKD 0327
B 47
B 47
Part Number
90-305-640
75-521-033
90-505-640
75-521-033
SM-5811-0000.01 ENG
