Service component part numbers

These part numbers concern assemblies and components that are intended solely for use by service
technicians. The position number references relate to the illustration of the components in Chapter 3.
7.5.1

S5 System separate components

Accessories for E/P pack

Item Name
A E/P pack
Pump and device slot (front)
A 17 Backplane
A 18 Switching power supply
A 6 Battery switching circuit board
A 7 12V/17Ah battery
A 12 System AC oulet
Automatic circuit breaker, 10A
AUX (CAN) slot
Discharge adapter slot
Ext. power output
Pump and device slot
(left or right side)
S5 mains power cable 6.6 m (complete)
A 5 Remote control for mains power switch
S5 E/P pack cover
S5 E/P pack mounting bracket
S5 E/P pack battery mounting plate
S5 E/P pack blind plate 7TE
Socket head screw DIN 912 M4x8
Washer DIN 127 5,3
Socket head screw DIN 912 M5x8
Washer DIN 127 5,3
Hexagon screw DIN 933 M5x8
SM-5811-0000.01 ENG
Number Part Number
28-98-00
97-103-662
HBP 0321 90-305-580
HLM-NT-S5 96-403-551
HUS 0318 90-305-550
96-405-002
97-103-801
96-143-118
97-103-664
97-103-665
96-250-116
97-103-663
Euro 97-103-690
75-521-517
28-98-09
28-98-11
28-98-08
28-??-??
71-115-011
71-120-528
71-115-025
71-120-528
71-115-032
