SORIN GROUP S5 System Service Instructions Manual page 33

Item name
16 S5 roller pump 150
17 S5 double roller pump 85
68 Pump housing
69 Switch
70 Control panel with
71 Touch screen
72 Keys
73 Setting knob
74 Pump head S5 RP 150
75 Pump head S5 DRP 85
76 S5 pump cover RP 150
77 S5 pump cover DRP 85
78 Tubing guide rollers
79 Thumbwheel for occlusion
adjustment
80 Rotation direction indicator for 79
81 Occlusion rollers
82 Tubing grip channel
83 Magnet
84 Opening for hand crank
SM-5811-0000.01 ENG
Operation
Switching the pump on and off
➜
Monitoring and displaying the pump functions and the
selected control and monitoring function
➜
Entering and displaying the pump parameters which
have been set
Override the monitoring functions
Sets the speed
e.g. for arterial blood flow
For low flow rates
Safety, pump can only operate with the cover closed
Keep the tubing in position
Moves the occlusion rollers inwards or outwards
Shows the direction of rotation when moving the occlusion
rollers outwards
Occlude the installed tubing
➜
Retains the installed tubing
➜
Removable strip with two tubing guide channels
Monitors whether the cover is closed or not
Enables the pump to be operated by hand in emergency
situations
S5 System • System description
3.13
