SORIN GROUP S5 System Service Instructions Manual page 143

Item Name
H 13 Shaft encoder with cable harness
(identical to shaft encoder on pumps)
H 26 S5 setting knob
H 27
Rubber ring
H 28 Grub screw DIN 916 M4x6
H 29 Washer PA 6.2 x 12.0 x 0.5
H 30
Nut for panel
◗
Remove PT screws K822x6 WN 1411.
◗
Pull the rubber ring H 27 upwards.
◗
Remove the grub screw H 28 using an allen key (xx).
◗
Pull the setting knob H 26, washer H 29 and nut H 30 off the shaft encoder H 13.
◗
Replace the shaft encoder as a complete unit only (with cable harness). Fit the shaft encoder in the
reverse order.
◗
Note when assembling: Sharp edges on the housing can damage cables or their insulation. Take care
to ensure that cables are not pinched.
Ensure that you do not position the shaft encoder cable harness close to the fan!
SM-5811-0000.01 ENG
Number Part number
97-103-608
10-85-14
75-521-529
71-118-317
71-120-514
10-89-13
S5 System • Replacing components
6.59
