Circuit board computer board

B 4
B 31
B 30
Fig. 26: Circuit board computer board
Item Name
B 4 Circuit board computer board
B 28 Socket connection speaker
B 29 Socket connection inverter
B 30 Socket connection power supply
B 31 Socket connection CAN bus
B 32 Socket for connector B 47
B 33 Socket connection shaft encoder RP150
(or PR 85 left)
B 34
Socket connection shaft encoder RP85 (right)
B 35 Socket connection serial flash and report
B 36 Socket connection touch screen
B 37
Socket connection LCD
B 38 Socket connection on circuit board motor
controller B 22 RP 150 (or RP 85 left)
B 39 Socket connection on circuit board motor
controller B 22 RP 85 (right)
3.42
B 39
B 29 B 28
B 38
Number Part Number
HKR 0325 90-305-620
CON 1
CON INV
CONCAN
CON 2
ENC A
ENC B
CON 3
CON TS
CON LCD
CONPA
CONPB
B 37
B 36
B 35
B 34
B 33
B 32
