SORIN GROUP S5 System Service Instructions Manual page 123

G 17
Fig. 71: Replacing the circuit board HME 0402 (3)
◗
Lift up the circuit board motor power amplifier MRP85 G 6 circuit board.
◗
Disconnect the following connectors from the circuit board G 6:
Item Name
Connection pump head G 17
Connection mast roller pump S5 control panel G 18
Connection fan G 20
◗
Replace the circuit board motor power amplifier MRP85 G 6.
SM-5811-0000.01 ENG
G 6 G 5
Number
CON 1
CON 2
CON 4
S5 System • Replacing components
G 20
G 18
Part number
6.39
