System panel

for 3 display and control modules
Height
Width
Depth (without mast holder)
Weight (without display and control module)
for 4 display and control modules
Height
Width
Depth (without mast holder)
Weight (without display and control module)
for 5 display and control modules
Height
Width
Depth (without mast holder)
Weight (without display and control module)
for 6 display and control modules
Height
Width
Depth (without mast holder)
Weight (without display and control module)
Display and control module
Height
Width
Depth
Weight
Control module for mast roller pumps
Height
Width
Depth
Weight (with holder)
7.4
475 mm
184 mm
94 mm
3.9 kg
590 mm
184 mm
94 mm
4.5 kg
723 mm
184 mm
94 mm
5.1 kg
475 mm
375 mm
94 mm
7 kg
125 mm
179 mm
48 mm
0.5 kg
260 mm
190 mm
100 mm
3.5 kg
