SORIN GROUP S5 System Service Instructions Manual page 66

S5 System • System description
Item Name
D 2 Backplane system panel
D 15 Plug connection speaker
D 16 Plug connection S5 System (CAN)
D 17 Plug connection line filter
D 18 Plug connection fan
D 19 Plug connection fan
D 20 Connection display and control module
D 21 Plug connection HDA 0406 D 22
D 14 Adapter Backplane system panel
D 22 Plug connection HDB 0406 D 21
D 23 Connection display and control module
3.46
Number Part Number
HDB 0406 90-305-740
CON 9 96-201-015
CON 6 96-201-098
CON 5 96-205-033
CON 8 96-201-035
CON 7 96-201-035
CON 1 - 4 96-215-123
CON 10 96-215-122
HDA 0406 90-305-890
CON 1 96-215-123
CON 2 96-215-123
SM-5811-0000.01 ENG
