S5 System • Replacing components

6.8 Connectors

When inserting the new cable ensure that the connections are correctly assigned. For overview the most
important connectors with pin assignment. Further information to the part numbers is provided in the
chapter 7.5 „Service component part numbers" on page 7.16.
6.8.1

E/P pack connectors

ODU plug

Fig. 95: ODU plug (e.g. connecting pumps and devices to system slots )

Amphenol plug

Fig. 96: Amphenol plug (connecting AC outlet connection to the E/P pack)
