S5 System • Appendix

Masts

Telescope masts
Height (from the floor)
Diameter (fixed part)
Movable mast
Height (from the floor)
Diameter (fixed part)
Horizontal mast
Length
3 position
4 position
5 position
Diameter
Maximum permissible load
Maximum total load on mast system
Maximum load on a mast
Maximum load on the infusion rack
Mast system extension (optional)
Maximum load on the telescope mast
Maximum load on the vertical mast
7.2
in the lowest configuration
in the highest configuration
1230 mm min.
1840 mm max.
1520 mm min.
2120 mm max.
Ø 33 mm
1520 mm min.
2120 mm max.
Ø 33 mm
806 mm
896 mm
1081 mm
Ø 25 mm
45 kg
20 kg (max. swivel arm 200 mm)
5 kg
40 kg
11.5 kg
SM-5811-0000.01 ENG
