S5 System • System description
3.2.3

Overview of S5 System Panel

System panel (standard)

Fig. 5: Front and back of the S5 system panel
Item name
14 S5 system panel
32 Display and control module with
33 Touch screen
34 Mast holder with
35 Fast clamp connector
36 Clamping lever
37 Switch
38 Cable CAN/24 V
3.8
32
33
Operation
With four module slots for supporting a maximum of
4 display and control modules with touch screens
Control and configuration of the S5 System
Positioning the S5 system panel on the mast system of the
S5 System
Fixing the mast holder or the connector
Switching the S5 system panel on and off
Power supply for the S5 system panel
14
34
35 36
38
37
