S5 System • Fault messages and troubleshooting
5.2 Operating the additional devices for the S5 System
Other additional devices can also be operated with the S5 System.
This includes connecting
– the Heater-Cooler System 3T
– various gas blender systems,
– the SCP system and
– the electrical remote-controlled tubing clamp
to the S5 System.
For information about the relevant alarm messages, see the S5 System operating instructions.
If an alarm is not cleared or other errors and faults are displayed, please refer to the separate operating
instructions or service manual for additional measures.
Other displays
General messages are also output on the System panel as well as the specific messages for the
individual devices:
Display on System menu
Please connect S3 devices
to the side jacks
5.8
Description
➜
possible cause/effect
◗
Steps to be taken
➜
An S3 additional device has been connected
incorrectly.
➜
Incorrect choice of connection cable.
◗
Check the connection to the S5 additional device. S5
devices 57 or 58 on the side.
SM-5811-0000.01 ENG
