SORIN GROUP S5 System Service Instructions Manual page 35

Item name
28 S5 mast roller pump system 150
76 to
84
85 S5 mast roller pump 150
(MRP 150 for short)
86 Pump head MRP 150
87 Connection cable (fixed)
88 Holder MRP 150
89 S5 control panel MRP 150/85 with
90 Touch screen
91 Keys
92 Setting knob
93 Cable CAN/24 V
94 Switch
29 S5 mast roller pump system 85
95 S5 mast roller pump 85
(MRP 85 for short)
96 Pump head MRP 85
97 Connection cable (fixed)
98 Holder MRP 85
31 S5 mast roller pump system 85
99 S5 mast roller pump 85
(MRP 85 for short)
100 S5 control panel for 2 MRP 85
101 Switch
102 Connection cable (fixed)
103 Double holder MRP 85
SM-5811-0000.01 ENG
Function
See page 3.13
consisting of:
– Pump head MRP 150
– Pump housing with drive unit and connection cable
e.g. for arterial blood flow
Connection to S5 control panel MRP 150/85 (back of the
housing)
Positioning the S5 MRP 150 on the mast system of the
S5 System
➜
Monitoring and displaying the pump function and the
selected control and monitoring function
➜
Entering and displaying the pump parameters
Overriding the monitoring functions
Setting the speed
Power supply for the S5 system panel MRP 150/85 and the
pump (connection to system slots 1-12)
Switching the control panel and the mast roller pump on
and off (back of the housing)
consisting of:
– Pump head MRP 85
– Pump housing with drive unit and connection cable
For low flow rates
Connection to S5 control panel MRP 150/85
(back of the housing)
Positioning the S5 MRP 85 on the mast system of
the S5 System
consisting of:
– 2 MRP 85 pump heads
– 2 pump housings, each with a drive unit and a separate
connection cable
Switching the control panel and the 2 MRP 85 on and off
(back of the housing)
Connection for S5 control panel MRP 85 (back of the
housing)
Positioning the S5 MRP 85 on the mast system of the
S5 System
S5 System • System description
3.15
