Electrical Specifications; Electronics And Power Pack; Ups And Batteries - SORIN GROUP S5 System Service Instructions Manual

7.1.2

Electrical Specifications

Device protection
Drip-proof

Electronics and power pack

Input voltages
Permissible mains voltage fluctuation
Maximum power consumption (standard equipment)
Mains power protection (implemented in mains power switch) Circuit breaker:
Circuit breaker system slots:
Circuit breaker F1 - F12 (for pumps and devices) One circuit breaker each, 10 A
Circuit breaker Module F13 for sensor module

UPS and batteries

Output voltage
Nominal voltage
Minimum voltage
Maximum voltage
Output power
Nominal output power
Capacity of new batteries
Fuse protection of batteries
Operating time of UPS
At 400 W output power
At 160 W output power
Charging time
Discharger
Input voltage
Current
Fuse protection of the discharger
SM-5811-0000.01 ENG
Protection class 1
Type B
IPX1
100 V~ to 240 V~; 50 / 60 Hz
± 10%
1000 W
10 A nominal trip current
Automatic circuit breaker 10 A
24 V
19 V
32 V
400 W
17 Ah
40 A
20 minutes
90 minutes
12-15 hours
24 V DC
8 A
10 A slow (DIN 41662)
S5 System • Appendix
7.5
