7.1.3

Pumps

Pump specifications
Diameter of pump raceway
Diameter of occlusion roller
Speed range
Deviation in speed accuracy
Speed deviation in the event of a fault
(Detection of faulty speed from 30 rpm)
Direction of rotation
Concentricity
Pump raceway
Occlusion symmetry
Occlusion rollers
Displays
rpm display range
Resolution
l/min display range (flow)
1/8"
3/16"
1/4"
5/16"
3/8"
1/2"
Deviation of speed slave pump
Power supply
Operating voltage
Power consumption
Power consumption for mast roller pump
Device protection
Touch screen
Pixel Failure Class
SM-5811-0000.01 ENG
Roller pump
150 mm
30.5 mm
0 to 250 rpm (clockwise, counterclockwise)
±1% of the terminal value 250 rpm plus ±0.5% of set value
during continuous operation:
+15% max.; 2 revolutions max. until pump stops
Clockwise/
counterclockwise
0.03 mm
0.03 mm
0.015 mm
0 to 250 rpm
1 rpm
0 to 0.83 l/min
0 to 1.79 l/min
0 to 3.12 l/min
0 to 4.70 l/min
0 to 6.50 l/min
0 to 11.2 l/min
max. 1 percentage point of the flow ratio setting
24 V DC
160 W
MRP 150: 160 W
IPX1 (drip-proof)
Conformity with Pixel Failure Class III
S5 System • Appendix
Double roller pump
85 mm
15 mm
Clockwise/
counterclockwise
0.03 mm
0.03 mm
0.015 mm
0 to 250 rpm
1 rpm
0 to 0.44 l/min
0 to 0.93 l/min
0 to 1.57 l/min
0 to 2.33 l/min
o
o
24 V DC
160 W
MRP 85: 80 W
7.9
