Circuit board fan control (control panel mast roller pumps)
H 6
H 16
Fig. 33: Circuit board fan control
Item
Name
H 6
Circuit board Fan control
H 16
Socket connection fan
H 17
Socket connection computer board H 4
3.50
H 17
Number
HDM 0503
CON 1
CON 2
Part Number
90-105-850
SM-5811-0000.01 ENG
