S5 System • Replacing components
6.4.2

Opening the pump housing

Fig. 66: Opening the pump housing
◗
If necessary, remove the pump cover.
◗
Remove the indicated head socket screws (DIN 912 M3x6 / allen key size 2.5 mm)
◗
Remove the indicated head socket screws (DIN 912 M3x6 / allen key size 2.5 mm)
◗
Carefully remove the housing.
6.34
(on base plate).
.
SM-5811-0000.01 ENG
