SORIN GROUP S5 System Service Instructions Manual page 10

S5 System • Introduction
◗
S5 system panel 4 position
(abbreviation: system panel)
◗
S5 display and control module
◗
Touch screen
(pressure-sensitive display)
◗
Display applet
(abbreviation: displet)
◗
Start page
◗
Main menu (Main page)
◗
System menu
◗
UPS menu
1.4
The modular control unit mounted on the mast comprises
4 module slots to take a maximum of 4 display and control
modules with touch screens.
Blank modules are plugged into slots which are not being
used.
Central interface between the user and the S5 System
comprising:
– Touch screen
– Housing
This is where
– All the values recorded by the sensors, the states and
the parameters defined by the user (such as limits) are
displayed
– The control functions are assigned to the
corresponding pumps
– The entire system is configured
The surface of the touch screen is divided up into several
displets (according to menu and display).
A display applet is the display of an application. This
application may concern displets for displaying the current
values (such as the measured pressure) or so-called entry
displets where parameters or limits can be entered.
The number of displets shown depends on the
configuration of the entire system, the menus which have
been selected and the current status of the heart-lung-
machine.
After switching on, if the self-test has run without any
faults (the S5 System and the system panel), the start page
will appear on the system panel.
The Start page is dependent on the total configuration of
the system and the parameters last saved in the
– System menu
– UPS menu
– Menus for the control and monitoring functions
– Menus for the monitoring functions
– Display menu
– Equipment menu (optional)
Overall display of all menus during operation on the
system panel.
This is where the:
– Displays date and time
– Displays alarm, warning and error messages
– Deletes, clears and silences pending alarms
This is where the:
– Monitor and control of UPS functions
– Shows the current operating state of the UPS
SM-5811-0000.01 ENG
