SORIN GROUP S5 System Service Instructions Manual page 25

Item name
18 S5 mast system extension
19 S5 telescope mast for mast system
extension with
20 Console casters and
21 Parking brake
22 Vertical mast
23 Horizontal masts
24 Swivel arm
25 Clamping lever
26 Transport locking arm with
27 Fast clamp connector
SM-5811-0000.01 ENG
Function
➜
for extending the S5 mast system
➜
Can be mounted on both sides of the S5 System on the
telescope mast 7
Locking the mast system extension in place during an
operation
➜
Mounting of additional equipment (in this case: a mast
roller pump)
➜
Mounting of disposable items
Mounting the vertical mast and stabilising the mast system
extension. The horizontal masts can be positioned as
required. The greater the distance between the two
horizontal masts, the greater the stability of the mast
system extension.
A minimum distance of 500 mm must be observed. Do not
attach any loads to the horizontal masts.
Mounting the mast system extension on the mast system
of the S5 System. The lower swivel arm can also be secured
below the console plate. The greater the distance between
the two swivel arms, the greater the stability of the mast
system extension.
A minimum distance of 600 mm must be observed. Do not
attach any loads to the swivel arms.
➜
Fixing the mast system extension during operations
➜
The clamping levers can be released when the S5
System is moved (e.g. to compensate for uneven floor
surfaces).
➜
Securing the mast system extension during transport
of the S5 System by fixing the fast clamp connector to
the telescope mast 19
➜
Installation on the push bar 6
S5 System • System description
!
!
3.5
