Assembly System Panel - SORIN GROUP S5 System Service Instructions Manual

Pump head pawl
Pawl mini S5
Pawl spring mini S5
Retaining ring mini
Socket head screw, DIN 912, M3x8
Socket head screw, DIN 912, M4x8
Socket head screw, DIN 912, M3x6
Spring washer, DIN 127, B 4
Spring washer, DIN 127, B 3
Self-locking nut, DIN 985, M3 (WAF 5.5 mm)
Distance bolts with internal/external thread M3x15
(WAF 5.5 mm)
Distance bolts with internal/external thread M3x12
(WAF 5.5 mm)
Distance bolts with internal/external thread M3x10
(WAF 5.5 mm)
Washer DIN 9021 3.2
Connection cable E/P pack S5 pump
Pump head RP85
Pump cover RP85 (complete)
Universal joint for cover RP85
Tubing guide rolls RP85
C 13 Motor power amplifier
C 14 Motor controller

Assembly System panel

Item Name
D S5 system panel, 3 pos.
Backplane board
S5 system panel, 4 pos.
Backplane board
S5 system panel, 5 pos.
Backplane board (identical pos. 4)
Adapter backplane board
SM-5811-0000.01 ENG
10-86-40
10-84-35
10-86-42
71-115-007
71-115-011
71-115-001
71-120-527
71-120-526
71-121-527
71-131-018
71-131-017
71-131-016
71-120-601
97-102-621
10-86-00
10-86-45
75-521-521
75-521-502
HMF 0408 90-305-760
HMS 0409 90-305-770
Number Part Number
28-95-03
HDT 0501 90-305-830
28-95-00
HDB 0406 90-305-740
28-95-01
HDB 0406 90-305-740
HDA 0604 90-305-890
S5 System • Appendix
7.27
