S5 System • Brief overview system panel
e Display Battery status
55
%
76
%
g Icon and display Time
3:11
4.4
f Display Battery charge
status
remaining
Bar graph of the battery charge status
– Battery test required or fault in the battery
– Batteries are fully charged
(bar graph with long arrow)
– During trickle charging
(bar graph with short arrow)
– Discharge phase of the battery test of UPS operation
(bar graph with long arrow)
Display of the battery charge status (in %) while charging:
– Yellow: below 60%
– White: above 60%
The battery charge status indicator is white during
discharge.
Icon and display of "battery discharge" with time
remaining display (yellow)
