S5 System • Appendix

Shelf with AC outlet

3/4/5
position

System panel

Display and control module / touchscreen
Operating voltage
Power consumption
Pixel Failure Class
Level
Alarm limit (level sensor) for oxygenators/reservoirs made of
rigid polycarbonate, wall thickness at sensor position 3 mm
max.
Pressure
Measurement range
Resolution
Cardioplegia
Pressure measurement range
Resolution
Temperature monitor
Display range
Timer
Counting range
Timer (optional)
Counting range
7.6
Weight - shelf
Maximum load - shelf
Number of sockets
Protection
Protection
Load rating
Sum of leakage currents
approx. 6.5 kg
8 kg
4
at 230/240 V: Circuit breaker 2 A
at 110/115 V: Circuit breaker 2 A
2 A maximum in total
500 μA max. in total
24 V
45 W
Conformity with Pixel Failure Class III
Level display of the sensor holder ±10 mm
-200 mm Hg to +800 mm Hg
1 mm Hg
-200 mm Hg to +800 mm Hg
1 mm Hg
0 •C to +50 •C
0 - 999 min 59 sec
0 - 10 h (up and down)
SM-5811-0000.01 ENG
