S5 System • Replacing components
Replacing the display and control module
D 9
Abb. 82: Replacing the circuit board display and control module
◗
In order to separate the circuit board display and control module D 10 of the frame, loosen the four
socket head screws (DIN 912 M3x6 / allen key size 2.5 mm).
◗
Carefully lift up the circuit board D 10.
Install the circuit board in the reverse order.
6.48
SM-5811-0000.01 ENG
