6.4 Mast roller pump MRP85/x
6.4.1
Removing the double holder
Fig. 65: Removing the double holder
◗
Remove cap a from the back of the double holder G 1.
◗
Remove the four head socket screws (DIN 912 M4x8 / allen key size xx mm).
◗
Replace the pump.
SM-5811-0000.01 ENG
S5 System • Replacing components
G 1
a
6.33
