SORIN GROUP S5 System Service Instructions Manual page 189

P4
FN332Z–10/05
Supply 24 V
we
P
sw
N
Schaffner
Conductive connection to the housing
96–401–012
via the screw connection of the filter
Cable–UL1007
AWG16 250 mm
P2
BU2-PHO with cable and blade terminal
97-101-938
HMF 90-305-760 HMS 90-305-770
CON2
CON3 CON1
ST26D–EHF BU26D–FL–7.5
CON4 CON1
ST2–W–MO–RM2.54 ST3–PHO
614-KONF NK812 V23401-D1401-E801
Papst Tyco
Parvex
96–406–031 96-407-051
96–407–041
Fig. 3: Overview wiring diagramm - Mast roller pumps MRP 150 and MRP 85)
SM-5811-0000.01 ENG
Supply 2 * 6 mm stripped
6–pin FCI plug
Cable–UL1007
Paar 1
120 mm LOC_CAN
Paar 2
INDEX
we +
P1–A
bn –
Kabel–S5–P
97-102-628
Conductive connection to the housing
via braided screen
Cable–UL1007
200 mm
P1–D
Cable–S5–P
A1 ge
A2 S LOC_CAN
gn Cable–S5–P
A3
ge
B1
B2 S INDEX
B3 gn
P1–E
Cable–UL1007
AWG16 120 mm
DIP-switch to positon EP!
ge/gn
Conductive connection to the housing
via cable lug M4 on the threaded bolt
HME 90-305-700
Mast roller pump MRP150
CON4
ST2–W–MO–RM2.54
614-KONF
Papst
96–406–031
Cable 2 m long
Supply 24 V
Cable–UL1007
AWG16 120 mm
P2
BU2-PHOENIX socket with shieled cable
97-101-936
HMR 90-305-710
CON2
CON3 CON1
ST26D–EHF BU26D–FL–7.5
CON1
ST3–PHO
NK408 V23401-D1401-E801
Parvex Tyco
96-407-051
96–407–045
S5 System • Appendix
Supply 2 * 6 mm stripped
6–pin FCI plug
Paar 1
LOC_CAN
Paar 2
INDEX
we +
P1–A
bn –
Cable–S5–P
97-102-629
Conductive connection to the housing
via braided screen
Cable–UL1007
120 mm
P1–D
Cable–S5–P
ge
A1
A2 S
LOC_CAN
Cable–S5–P
A3 gn
ge
B1
S INDEX
B2
B3 gn
P1–E
Mast roller pump MRP85
Cable 2 m long
7.x
