Monitoring function
◗
Menus for the control and monitoring
functions
◗
Menus for the monitoring function
◗
Display menu
◗
Pump menu
◗
Equipment menu (optional)
◗
Functional group
SM-5811-0000.01 ENG
The term "monitoring function" may also include a control
associated with it. A control in this instance can be the
result of a monitored process. In order to avoid the use of
different terms, therefore, the term "monitoring function"
will be used consistently throughout.
The following menus (and corresponding sensor modules
and sensors) are used to control operation and intervene in
the pump control system when there is an alarm:
– Pressure menu
– Level menu
– Bubble menu
– Cardioplegia menu
The following menus (and corresponding sensor modules
and sensors) can be used to trigger an alarm which,
however, does not intervene in the pump control system:
– Temperature menu
These menus only have a display function:
– Timer
This is where the:
– Pump parameters are entered
– The blood/cardioplegia and stop link pumps are
assigned
The control panel for external units appears on the
displets.
Parameters can be entered or assigned.
e.g. gas blender (optional)
The displet on the display and control module on the
system panel, the sensor module in the E/P pack and the
corresponding sensor (or sensors) represent a "functional
group" (e.g. "Temperature monitor" displet and sensor
module and the temperature probes).
Although all entry and display displets are combined on
the system panel, each functional group operates
independently.
S5 System • Introduction
1.5
