Pulse Mode Control for SCP/S5
Pulse frequency
Pulse flow percentage
Minimum pulse duration
Base flow percentage
Deviation
APC
Accuracy of volume measurement
Accuracy of time measurement

Modules and sensors

All sensor modules
Operating voltages
Power consumption
Level sensor module
Alarm limit (level sensor) for oxygenators/reservoirs made of
rigid polycarbonate, wall thickness at sensor position 3 mm
max.
Sensor module for bubble detector and sensor module APC
Alarm limit (bubble sensor) at N 15 rpm
1/2" and 3/8"
1/4" and 3/16"
Sensor module 2 channel pressure monitor
Accuracy
Zero point adjustment range
Gain adjustment range (matching)
Input resistance
Output voltage to pressure transducer
SM-5811-0000.01 ENG
40 to 80 beats per minute
(adjustable in increments of 5)
50% (not adjustable)
M 300 ms
50% (not adjustable)
-15% to +5% (flow rate accuracy between
pulse and non-pulse mode)
(air and blood are suctioned)
when delivering pure liquid ±10% min. ±
20 ml
± 1s sec
+5 V (from DC/DC module)
24 V (system voltage)
3 W
Level display of the sensor holder ±10 mm
Alarm limit "Large" Air volume: 0.144 cm
Alarm limit "Medium" Air volume: 0.065 cm
Alarm limit "Small" Air volume: 0.034 cm
Alarm limit "Small 1/4" " Air volume:
3
0.034 cm (Ø 4.0 mm)
± 5 mm Hg
± 100 mm Hg
± 20%
100 kT
< 10 V
S5 System • Appendix
3
(Ø 6.5 mm)
3
(Ø 5.0 mm)
3
(Ø 4.0 mm)
7.7
