5

Fault messages and troubleshooting

The S5 system undergoes continuous self-monitoring. Faults that occur (e.g. the failure of a component)
are displayed in the system menu.
5.1

Fault messages

5.1.1

Unspecified faults

Note:
Even if
– all pumps are switched off,
– the system panel is switched off,
– the mains power cable is unplugged,
– and the E/P pack is switched on,
it is still possible that the batteries are totally discharged. In this case, take the appropriate steps
described in chapter 5.1.2.
Fault Description/possible cause
System does not start Defective switch
although batteries are
charged
System does not start Mains power cable missing
with discharged or
missing batteries Transformer/terminal block
Defective switch
Defective line filter
Defective rectifier
System starts (can be Circuit breaker for system
heard), but touch screen panel socket has triggered/
remains dark is defective
Faulty contact
Back plane board of system
panel defective
SM-5811-0000.01 ENG
or defective
wired wrongly
S5 System • Fault messages and troubleshooting
Steps to be taken
(please proceed in the order listed)
– Check/replace switch
– Connect/check mains power cable
– Check wiring/terminal block
– Check/replace switch
– Check/replace line filter
– Check/replace rectifier
– Check / reset / replace safety cut-out
– Check / replace wiring in E/P pack to system panel
socket
– Check / replace system panel cable CAN/24 V
– Check / replace system panel switch
Replace complete system panel
!
5.1
