SORIN GROUP S5 System Service Instructions Manual page 111

Item Name
B 54 Shaft encoder with cable harness
B 55 S5 setting knob
B 56 Rubber ring
B 57 Threaded rod, DIN 916 M4x6
B 58 Washer PA 6,2 x 12,0 x 0,5
B 59 Nut for panel
◗
Loosen the PT screws K822x6 WN 1411.
◗
Pull the rubber ring B 56 upwards.
◗
Loosen the set screw B 57 with an Allan key (xx).
◗
Pull the setting knob B 55, the washer B 58 and the nut B 59 from the shaft encoder B 54.
◗
Always replace the shaft encoder assembly as a complete unit (with cable harness). Install the shaft
encoder in the reverse order.
SM-5811-0000.01 ENG
Number Part Number
97-103-608
10-85-14
10-85-14
71-118-317
71-120-514
10-89-13
S5 System • Replacing components
6.27
