SORIN GROUP S5 System Service Instructions Manual page 50

S5 System • System description
Item Name
E 1 S5 mains power connection module
E 2 S5 UPS module
Circuit board UPS charging device
Circuit board UPS control
E 3 S5 DC/DC module
Circuit board DC/DC
E 4 S5 System boards
System board A
System board B
E 5 S5 Sensor module APC (optional)
Sensor board (bubble detector)
E 6 S5 Sensor module bubble detector
Sensor board (bubble detector)
E 7 S5 sensor module level monitor
Sensor board (level monitor)
E 8 S5 sensor module 2-channel pressure monitor
Sensor board (pressure monitor)
E 9 S5 sensor module cardioplegia control
Sensor board (cardioplegia)
E 10 S5 sensor module 4-channel temperature monitor
Sensor board (temperature monitor)
E 11 S5 interface I4D
Sensor board (interface I4D)
3.30
Number Part Number
29-12-30
28-98-80
HUL 0319 90-305-560
HUK 0320 90-305-570
28-98-20
HDC 0322 90-305-590
HEK 0411 90-305-790
HEX 0412 90-305-800
23-45-22
HSB 0329 90-305-660
23-45-20
HSB 0329 90-305-660
23-40-20
HSL 0401 90-305-690
20-20-20
HDR 0324 90-305-610
29-02-50
HSK 0405 90-305-730
20-30-20
HST 0328 90-305-650
29-02-50
HIS 0413 90-305-810
SM-5811-0000.01 ENG
