SORIN GROUP S5 System Service Instructions Manual page 45

Item Name
C S5 double roller pump 85 / S5 DRP85
C 1 Control panel DRP85
C 2 LCD touch screen
C 3 Circuit board keys and LEDs
C 4 Computer board
C 5 Pressure switch
C 6 Speaker
C 7 Fan (not shown)
C 8 Line filter
C 9 Retaining ring mini
C 10 Connection cable DRP85 (not shown)
C 11 Pump head RP85
C 12 Pump cover RP85 (complete)
C 13 Motor power amplifier
C 14 Motor controller
SM-5811-0000.01 ENG
Number Part Number
10-85-00
10-85-50
97-103-616
HKD 0327 90-505-640
HKR 0325 90-305-620
C 7000 AF 96-110-020
97-103-669
Pabst 614 24V 96-406-031
FN332Z-10-05 96-401-012
10-86-42
97-102-621
10-86-00
10-86-45
HMF 0408 90-305-760
HMS 0409 90-305-770
