SORIN GROUP S5 System Service Instructions Manual page 40

S5 System • System description
A 18
Fig. 11: Assembly overview – E/P pack (2)
Item Name
A E/P pack
A 12 System AC oulet
A 13 3 automatic circuit breakers 10 A for pump and device
slot (right)
A 14 6 automatic circuit breakers 10 A for pump and device
slot (front)
A 15
3 automatic circuit breakers 10 A for pump and device
slot (left)
A 16 Automatic circuit breaker 10 A for sensor modules
A 17 Backplane (for details see Page 3.36)
A 18 Switching power supply (for details see Page 3.21)
3.20
A 12
Number
HBP 0321
HLM-NT-S5
A 13
A 14
A 15
A 16
A 17
Part Number
28-98-00
97-103-801
90-305-580
96-403-551
SM-5811-0000.01 ENG
