Overview backplane system panel (3 pos. and 6 pos.)

D 12
D 15
D 17
Fig. 30: Backplane system panel (3 pos. and 6 pos.)
Item Name
D 12 Backplane system panel
D 15 Plug connection speaker
D 16 Plug connection S5 System (CAN)
D 17 Plug connection line filter
D 18 Plug connection fan
D 19 Plug connection fan
D 20 Connection display and control module
SM-5811-0000.01 ENG
D 18
D 16
Number
HDB 0406
CON 9
CON 6
CON 5
CON 8
CON 7
CON 1 - 3
S5 System • System description
D 19
D 20
Part Number
90-305-740
96-201-015
96-201-098
96-205-033
96-201-035
96-201-035
96-215-123
3.47
