Assembly Sensor modules

Item Name
Assembly material/gen. accessories:
Screws, DIN 966 M3x8
Screws, DIN 7985 M3x8
Screws, DIN 84 M2.5x6
Screws, DIN 966 M2.5x8
Side panel 100
Cover 7TE
Cover 7TE (slotted)
E 1 S5 mains power connection module
Mains power input socket
Cable harness (connection switch/circuit breaker)
Cable harness (mains power module output)
Cable channel, mains power
Front plate (mains power module)
Safety switch, 10A
Earthing bolt, M6
Shoulder screws M2.5 x 12.3
E 2 S5 UPS module
Circuit board UPS charger unit
Circuit board UPS control
Front plate (UPS module)
Shoulder screws M2.5 x 12.3
Fan
E 3 S5 DC/DC module
Board DC/DC
Front plate (DC/DC module)
Shoulder screws M2.5 x 12.3
E 4 S5 System boards
System board A
System board B
SM-5811-0000.01 ENG
Number Part Number
71-103-026
71-103-325
71-116-014
71-116-015
73-100-130
73-100-132
73-100-134
29-12-30
96-250-115
HBP 0321 97-101-926
97-101-927
96-510-055
29-12-36
96-143-018
96-221-029
73-110-142
28-98-80
HUL 0319 90-305-560
HUK 0320 90-305-570
28-98-86
73-110-142
Papst 412 FM 96-406-006
28-98-20
HDC 0322 90-305-590
28-96-26
73-110-142
HEK 0411 990-305-790
HEX 0412 990-305-800
