Assembly DRP 85
Item Name
C
S5 double roller pump 85 / S5 DRP85
Control panel DRP85
S5 rotary knob
Rotary ring
Threaded rod, DIN 916, M4x6
Nut for panel
LCD touch screen with cable
Insulating film for LCD touch screen
C 3 Display and monitoring board
Shaft encoder S5 with cable harness
Display carrier RP
Inverter bracket
Inverter
Computer board
EMC sealing cord
Gasket for LCD touch screen
LED light guide, 7-element
PT Screws K822x6 WN 1411
Washer PA 6,2 x 12,0 x 0,5
Housing-mounted components:
C 5
Pressure switch
Speaker with cable harness, 250 cm
Base plate (complete)
C 7
Fan without cable harness
Fan screen EMC 60x60
Distance plate for fan
Push rivet (d3.5/5.5 - 6.5 mm)
C 8 Line filter
Hex Nut DIN 934 M3 (WAF 5.5 mm)
Spare pump
7.26
Number Part Number
10-85-00
10-85-50
10-80-14
75-521-529
71-118-317
10-85-13
97-103-616
72-102-074
HKD 0327 90-305-640
97-103-608
10-85-15
28-95-22
LXM1617-05-6x 93-146-026
HKR 0325 90-305-620
96-530-127
72-102-018
75-521-033
71-119-825
71-120-514
C 7000 AF 96-110-020
97-103-669
10-84-41
Pabst 614, 24V 96-406-031
10-84-42
10-84-43
96-520-063
FN332Z-10-05 96-401-012
71-121-502
75-521-524
