SORIN GROUP S5 System Service Instructions Manual page 178

S5 System • Appendix
E 5 S5 5 sensor modul APC
Sensor board (bubble detector)
Front plate (bubble monitor)
Shoulder screws M2.5 x 12.3
Socket LEMO 5-conductor. EGG.1B.305.CLL
E 6 S5 sensor module bubble detector
Sensor board (bubble detector)
Front plate (bubble monitor)
Shoulder screws M2.5 x 12.3
Socket LEMO 5-conductor. EGG.1B.305.CLL
E 7 S5 sensor module level monitor
Sensor board (level monitor)
Front plate (level monitor)
Shoulder screws M2.5 x 12.3
Socket LEMO 3-conductor. EGG.0B.303
E 8 S5 sensor module 2-channel pressure monitor
Sensor board (pressure monitor)
Front plate (pressure monitor)
Shoulder screws M2.5 x 12.3
Diode socket pressure S5 in cable harness
E 9 S5 sensor module cardioplegia control
Sensor board (cardioplegia)
Front plate (cardioplegia)
Shoulder screws M2.5 x 12.3
Diode socket pressure S5 in cable harness
Socket LEMO 5-conductor. EGG.1B.305.CLL
E 10 S5 sensor module 4-channel temperature monitor
Sensor board (temperature monitor)
Front plate (temperature monitor)
Shoulder screws M2.5 x 12.3
7.30
23-45-22
HSB 0329 90-305-660
23-45-26
73-110-141
96-250-042
23-45-20
HSB 0329 90-305-660
23-45-26
73-110-141
96-250-042
23-40-20
HSL 0401 90-305-690
23-40-26
73-110-141
96-250-031
20-20-20
HDR 0324 90-305-610
22-20-26
73-110-141
97-103-660
29-02-50
HSK 0405 90-305-730
29-02-56
73-110-141
97-103-660
96-250-042
20-30-20
HST 0328 90-305-650
20-30-26
73-110-141
SM-5811-0000.01 ENG
