SORIN GROUP S5 System Service Instructions Manual page 191

Ribbon cable
(for inverter)
96-231-042
Shaft encoder
97-103-608
Fig. 5: Overview wiring diagramm - Control panel for mast roller pumps
SM-5811-0000.01 ENG
Cable set
97-101-935
FFC
96-231-043
Fan:
as far away from
shaft encoder ribbon cable as possible!
MRP system socket
97-103-670
(für 28-95-85)
ArtNr: 75-521-516
Datum/Werkstoff
Connection cable
97-102-628
Fan Speaker
96-406-030 97-103-669
S5 System • Appendix
7.x
