SORIN GROUP S5 System Service Instructions Manual page 57

Item Name
A 17 Backplane (complete)
A 24 Block for connection of DC/DC module
A 25 Plug connection speaker
A 26 Connection system slots (left)
A 27 Connection system slots (front)
A 28 Connection system slots (right)
A 29 Connection UPS module
A 30 Connection battery switching circuit board
A 31 Plug connection power supply
A 32 Connection system boards (HEK 0411 and HEX 0412) CON 19
A 33 Connection AUX 1
A 34 Connection AUX 2
A 35 Connection interface and sensor modules
SM-5811-0000.01 ENG
Number Part Number
HBP 0321 90-305-580
CON 1 96-215-125
CON 2 96-201-015
CON 4-6
CON 7-12
CON 13-15
CON 16 96-215-125
CON 17 96-215-125
CON 18 96-205-051
96-215-252
CON 20
CON 21
CON 24-33 96-215-123
S5 System • System description
3.37
