S5 System • Brief overview system panel
Status display OK
Key icon Clear alarm
Key icon Audio off
(Tone off)
Key icon Override
Icon Entry displet
Pressure unit mmHg
The key icons and displays listed above always have the same function and meaning. The following
sections explain the special, non-general key icons and displays of the individual menus.
Only those key icons which can be pressed in the menu shown are displayed (e.g. the key icon Scroll in
the System menu).
When a key icon is pressed, it briefly appears yellow. Activated functions are indicated by a vertical bar
in the key icon (on the left side).
4.2
Display green
(Display for the time being only applies to bubble activity)
– Bubble sensor connected
– No bubbles
– Clears the alarm indicated in the System menu, after
the cause of the alarm has been eliminated.
– Clears the bubble alarm, after the cause of the alarm
has been eliminated.
Switches currently active alarm and warning tones
(temporarily) off. If another alarm condition occurs, the
corresponding tone will sound again.
A warning tone can be activated or deactivated in the menu
of the corresponding monitoring function. This is not the
case for alarm tones.
Temporarily switches off an alarm which is pending. There
is a difference between:
– selective override of the corresponding monitoring
function in the System menu (time limited: 5 minutes)
– on the pumps: overriding all assigned monitoring
functions (time limited)
Consists of a key icon and a display.
The key icon Entry displet opens the
– alphanumeric displet (see operating Instructions),
– numeric displet (see operating Instructions),
– lists displet (see operating Instructions),
– or an additional sub-menu (for further entry or display)
The parameters which have been entered appear on the
display (in this example: the pressure should be displayed
in mmHg.)
