S5 System • Fault messages and troubleshooting
5.1.2

Fault messages

The following applies with regard to all displayed fault messages:
◗
Check mains power cable connection
◗
Check (and where necessary clean) connector of the relevant or displayed components.
◗
Check the connector cable for blockages/short-circuits (where necessary replace connector cable).
◗
Check wiring of relevant or displayed components (e.g. for cable breaks).
◗
Restart the S5 system (i.e. the pump).
For persistent fault messages, please refer to the following section for information on further steps to
take:

Fault on pump

Display in system menu
Turn-off path faulty
Pump 1
Direction of rotation fault
Pump 1
Runaway fault
Pump 1
Runaway fault software
Pump 1
Motor monitoring/control failed
Pump 1
5.2
Description
➜
possible cause/effect
◗
Steps to be taken (please proceed in the order listed)
A fault has been detected during the self-test.
The pump fails to switch itself off (e. g. ramp-up) (in this case:
pump 1).
➜
Cable break
➜
Fault in circuit board Computer board (HKR 0325)
◗
Replace cable
◗
Replace circuit board HKR 0325
◗
where necessary send pump to manufacturer for checking
The pump ran in the wrong direction (without having been
instructed to do so).
◗
Send pump to manufacturer for checking.
The pump ran too fast (without being instructed to do so).
◗
Send pump to manufacturer for checking.
A safety feature of the pump has failed.
➜
Cable break
➜
Hall sensor defective
➜
Fault in circuit board.
Circuit board Motor control (HMS 0409)
◗
Check (and where necessary replace) connector cable
from motor control to circuit board HKR 0325
◗
Replace motor (hall sensors)
◗
Replace circuit board HMS 0409
◗
where necessary send pump to manufacturer for checking
