• Write data to the I/O data "Write" area by users with the program. Users can read data from the I/O data "Read" area with
the program. Never attempt to write data to the area indicated by "Read/write disabled" or "Read"; otherwise, normal
operation can no longer be performed. Note that, when starting control from the initial status, the data areas must be
cleared by the program.
• If the total number of device points for the number of loops used exceeds the last device number, an error occurs and no
processing is performed.
• Even when the manual manipulated value (MV
every scan. Unless the S(P).PIDCONT instruction is executed, the bumpless function cannot be performed.
• Apply an interlock using the READY signal of each module so that the S(P).PIDCONT instruction is executed only when the
A/D converter module used to obtain the process value (PV) and the D/A converter module used to output the manipulated
value (MV) are normal.
(1) (2)
(1) Control command
(2) READY signal of the A/D converter module
(3) READY signal of the D/A converter module
If the instruction is executed when these modules are not normal, PID operation cannot be performed normally as the result of
failure in normal acquisition of process values (PV) or in normal output of manipulated values (MV).
Operation error
Error code Description
(SD0)
3405H The value of the data set in the I/O data area specified by (s) is out of the setting range.
3422H The S(P).PIDINIT instruction is not executed before the S(P).PIDCONT instruction.
) is output in manual mode, execute the S(P).PIDCONT instruction
MAN
(3)
S.PIDCONT D100
