To do...
Terminate the connection to the
remote SFTP server and return
to user view

SFTP Client Configuration Example

Network requirements
As shown in Figure
SFTP client, logs in to Switch B for file management and file transfer. An SSH user uses publickey
authentication with the public key algorithm being RSA.
Figure 2-1 Network diagram for SFTP client configuration
Configuration procedure
1) Configure the SFTP server (Switch B)
# Generate RSA and DSA key pairs and enable the SSH server.
<SwitchB> system-view
[SwitchB] public-key local create rsa
[SwitchB] public-key local create dsa
[SwitchB] ssh server enable
# Enable the SFTP server.
[SwitchB] sftp server enable
# Configure an IP address for VLAN interface 1, which the SSH client uses as the destination for SSH
connection.
[SwitchB] interface vlan-interface 1
[SwitchB-Vlan-interface1] ip address 192.168.0.1 255.255.255.0
[SwitchB-Vlan-interface1] quit
# Set the authentication mode on the user interfaces to AAA.
[SwitchB] user-interface vty 0 4
[SwitchB-ui-vty0-4] authentication-mode scheme
# Set the protocol that a remote user uses to log in as SSH.
[SwitchB-ui-vty0-4] protocol inbound ssh
[SwitchB-ui-vty0-4] quit
Use the command...
bye
exit
quit
2-1, an SSH connection is established between Switch A and Switch B. Switch A, an
Required.
Use any of the commands.
These three commands
function in the same way.
2-6
