Configuration Prerequisites

The authentication mode for login users has been configured on the AUX user interface.
The modem dialup configuration environment is ready.
Configuration Procedure
Follow these steps to configure the switch-side modem:
To do ...
Enter system view
Enter AUX user interface view
Enable the modem to accept
incoming calls, initiate outgoing
calls, or both
Configure the modem to
operate in the auto-answer
mode
Set the maximum amount of
time that the modem waits for
the carrier signal after the
off-hook action during incoming
call connection setup
Configuration Example
Network requirements
Configure the switch-side modem to allow both incoming calls and outgoing calls, and configure the
modem to operate in the auto-answer mode. Set the timeout time that the modem waits for the carrier
signal after the off-hook action during incoming call connection setup to 45 seconds.
Network diagram
See Figure 4-1.
Configuration procedure
# Enter AUX user interface view.
<Sysname> system-view
System View: return to User View with Ctrl+Z.
[Sysname] user-interface aux 0
# Configure the modem to allow both incoming calls and outgoing calls.
[Sysname-ui-aux0] modem both
# Configure the modem to operate in the auto-answer mode.
[Sysname-ui-aux0] modem auto-answer
# Set the timeout time to 45 seconds.
[Sysname-ui-aux0] modem timer answer 45
Use the command ...
system-view
user-interface aux
first-number [ last-number ]
modem [ both | call-in |
call-out ]
modem auto-answer
modem timer answer
seconds
4-5
Remarks
—
—
Required
Optional
Manual answer mode applies
by default.
Optional
30 seconds by default
