Configuring A Dlsw Test - 3Com S7906E Configuration Manual

To do...
Configure the size of a probe
packet to be sent
Configure the filler string of a
probe packet sent
Configure the number of
packets sent in a voice probe
Configure the interval for
sending packets in a voice
probe
Configure the timeout for
waiting for a response in a
voice test
Configure common optional
parameters
Only one probe can be made in one voice test, and the number of probe packets sent in each probe
depends on the configuration of the probe packet-number command.

Configuring a DLSw Test

A DLSw test is used to test the response time of the DLSw device.
Configuration prerequisites
Enable the DLSw function on the peer device before DLSw test.
Configuring a DLSw test
Follow these steps to configure a DLSw test:
To do...
Enter system view
Enter NQA test group view
Configure the test type as
DLSw and enter test type view
Use the command...
data-size size
data-fill string
probe packet-number
packet-number
probe packet-interval
packet-interval
probe packet-timeout
packet-timeout
Refer to Configuring Optional
Parameters Common to an
NQA Test Group
Use the command...
system-view
nqa entry admin-name
operation-tag
type dlsw
1-18
Remarks
Optional
By default, the probe packet
size depends on the codec
type. The default packet size is
172 bytes for G.711A-law and
G.711 µ-law codec type, and is
32 bytes for G.729 A-law codec
type.
Optional
By default, the filler string of a
probe packet is the
hexadecimal number
00010203040506070809.
Optional
1000 by default.
Optional
20 milliseconds by default.
Optional
5000 milliseconds by default.
Optional
Remarks
—
—
Required
