[SwitchC] display mpls lsp
------------------------------------------------------------------
------------------------------------------------------------------
FEC
-/-
[SwitchA] display mpls static-cr-lsp
total statics-cr-lsp : 1
Name FEC
Tunnel0 3.3.3.3/32
[SwitchB] display mpls static-cr-lsp
total statics-cr-lsp : 1
Name FEC
Tunnel0 -/-
[SwitchC] display mpls static-cr-lsp
total statics-cr-lsp : 1
Name FEC
Tunnel0 -/-
On an MPLS TE tunnel configured using a static CR-LSP, traffic is forwarded directly based on label at
the transit nodes and egress node. Therefore, it is normal that the FEC field in the sample output is
empty on Switch B and Switch C.
7) Create a static route for routing MPLS TE tunnel traffic.
[SwitchA] ip route-static 3.2.1.2 24 tunnel 0 preference 1
Perform the display ip routing-table command on Switch A. You can find a static route entry with
interface Tunnel 0 as the outgoing interface.
MPLS TE Using RSVP-TE Configuration Example
Network requirements
Switch A, Switch B, Switch C, and Switch D are running IS-IS and all of them are Level-2 devices.
Use RSVP-TE to create a TE tunnel from Switch A to Switch D.
LSP Information: STATIC CRLSP
In/Out Label In/Out IF
20/30 Vlan1/Vlan2
LSP Information: STATIC CRLSP
In/Out Label In/Out IF
30/NULL Vlan1/-
I/O Label
NULL/20
I/O Label
20/30
I/O Label
30/NULL
Vrf Name
Vrf Name
I/O If
-/Vlan1
I/O If
Vlan1/Vlan2
I/O If
Vlan2/-
