Figure 1-9 SSH client configuration interface 2)
In the window shown in
the username. After entering the correct username (client002), you can enter the configuration
interface.
SSH Client Configuration Examples
When Switch Acts as Client for Password Authentication
Network requirements
As shown in
through the SSH protocol.
The username of the SSH client is client001 and the password is aabbcc. Password
authentication is required.
Figure 1-10 Switch acts as client for password authentication
Configuration procedure
1)
Configure the SSH server
# Create RSA and DSA key pairs and enable the SSH server.
<SwitchB> system-view
[SwitchB] public-key local create rsa
Figure
1-9, click Open. If the connection is normal, you will be prompted to enter
Figure
1-10, Switch A (the SSH client) needs to log into Switch B (the SSH server)
1-20
