Identifying And Diagnosing Pluggable Transceivers; Introduction To Pluggable Transceivers; Identifying Pluggable Transceivers - 3Com S7906E Configuration Manual

To do...
Enable expansion memory
data recovery function on a
card (distributed device)
Enable expansion memory
data recovery function on a
card (distributed IRF device)
This function is only available to EA LPUs and LSQ1SRP1CB SRPUs.

Identifying and Diagnosing Pluggable Transceivers

Introduction to pluggable transceivers

At present, four types of pluggable transceivers are commonly used, as shown in
be further divided into optical transceivers and electrical transceivers based on transmission medium.
Table 1-3 Commonly used pluggable transceivers
Transceiver type
SFP (Small
Form-factor
Pluggable)
GBIC (Gigabit
Interface Converter)
XFP (10-Gigabit small
Form-factor
Pluggable)
XENPAK (10-Gigabit
Ethernet Transceiver
Package)

Identifying pluggable transceivers

As pluggable transceivers are of various types and from different vendors, you can use the following
commands to view the key parameters of the pluggable transceivers, including transceiver type,
connector type, central wavelength of the laser sent, transfer distance and vendor name or name of the
vendor who customizes the transceivers to identify the pluggable transceivers.
Follow these steps to identify pluggable transceivers:
Use the command...
mmu-monitor enable slot
slot-number
mmu-monitor enable chassis
chassis-number slot
slot-number
Application
environment
Generally used for
100M/1000M Ethernet
interfaces or POS
155M/622M/2.5G
interfaces
Generally used for
1000M Ethernet
interfaces
Generally used for
10G Ethernet
interfaces
Generally used for
10G Ethernet
interfaces
1-17
Optional
Enabled by default.
Optional
Enabled by default.
Whether can be an
optical transceiver
Yes
Yes
Yes
Yes
Remarks
Table 1-3. They can
Whether can be an
electrical transceiver
Yes
Yes
No
Yes
