Step 2: Create a subdirectory named Device under directory /var/log/, and create file info.log under
the Device directory to save logs of Device.
# mkdir /var/log/Device
# touch /var/log/Device/info.log
Step 3: Edit file /etc/syslog.conf and add the following contents.
# Device configuration messages
local4.info
In the above configuration, local4 is the name of the logging facility used by the log host to receive logs.
info is the information level. The Unix system will record the log information with severity level equal to
or higher than informational to file /var/log/Device/info.log.
Be aware of the following issues while editing file /etc/syslog.conf:
Comments must be on a separate line and begin with the # sign.
No redundant spaces are allowed after the file name.
The logging facility name and the information level specified in the /etc/syslog.conf file must be
identical to those configured on the device using the info-center loghost and info-center source
commands; otherwise the log information may not be output properly to the log host.
Step 4: After log file info.log is created and file /etc/syslog.conf is modified, you need to issue the
following commands to display the process ID of syslogd, kill the syslogd process and then restart
syslogd using the –r option to make the modified configuration take effect.
# ps -ae | grep syslogd
147
# kill -HUP 147
# syslogd -r &
After the above configurations, the system will be able to record log information into the log file.

Outputting Log Information to a Linux Log Host

Network requirements
Send log information to a Linux log host with an IP address of 1.2.0.1/16;
Log information with severity higher than informational will be output to the log host;
All modules can output log information.
Figure 1-3 Network diagram for outputting log information to a Linux log host
Configuration procedure
Before the configuration, make sure that there is a route between Device and PC.
/var/log/Device/info.log
