To do...
Enable global MPLS TE
Exit to system view
Enter the interface view of an
MPLS TE link
Enable interface MPLS TE
Exit to system view
Create a tunnel interface and
enter its view
Assign an IP address to the
tunnel interface
Set the tunnel protocol to MPLS
TE
Configure the destination
address of the tunnel
Configure the tunnel ID of the
tunnel
Submit the current tunnel
configuration
Depending on the MPLS TE signaling protocol a tunnel uses, the basic capabilities you configured
in this section may be inadequate for the tunnel to work and you may need to make extra
configurations.
For information about tunnel interfaces, refer to Tunneling Configuration in the IP Services Volume.

Creating MPLS TE Tunnel over Static CR-LSP

Creating MPLS TE tunnels over static CR-LSPs does not involve configuration of tunnel constraints or
the issue of IGP TE extension or CSPF. What you need to do is to create a static CR-LSP and a TE
tunnel using static signaling and then associate them.
Despite its ease of configuration, the application of MPLS TE tunnels over static CR-LSPs is restricted
because they do not accept bandwidth constraints and cannot dynamically adapt to network changes.
Static CR-LSPs are special static LSPs. They share the same constraints and use the same label
space.
Configuration Prerequisites
Before making the configuration, do the following:
Configure static routing or an IGP protocol to make sure that all LSRs are reachable.
Use the command...
mpls te
quit
interface interface-type
interface-number
mpls te
quit
interface tunnel
tunnel-number
ip address ip-address
netmask
tunnel-protocol mpls te
destination ip-address
mpls te tunnel-id tunnel-id
mpls te commit
1-15
Remarks
Required
Disabled by default
––
––
Required
Disabled by default
––
Required
Required
Required
Required
Required
Required
