2. If the fault is temporary (temporal, localized, random):
a) The fault occurs at a specific position or area  Examine position or area.
If the examination of a position or an area was unsuccessful, the following components must be checked:
ProfiDAT
o
ProfiDAT
o
System layout: General check.
o
Environment: General check.
o
b) The fault occurs in a specific vehicle constellation  Examine particularities of vehicle constellation.
If the examination of the vehicle constellation was not successful, the following components must be checked:
ProfiDAT
o
comparison to a functionally trouble-free vehicle constellation.
ProfiDAT
o
HF component (cabling, antenna) and equipotential bonding: General check.
o
System layout: General check.
o
Environment: General check.
o
c) The fault occurs at a specific time  Check properties at this specific time more closely.
If checking properties at this time was not successful, the following components must be checked:
ProfiDAT
o
System layout: General check.
o
Environment: General check.
o
d) The fault occurs randomly  A narrowing down is not possible and the entire system must be checked.
